ABBPowerMark Gold load centers - Riser panels1TQC163200E0019 - DET223D

ABB Riser panel (PowerMark Gold). Model 1TQC163200E0019. Single-phase, 125A and 200A; 12, 20, and 40 circuits; 4 5/8" gutter for tap kits; Accepts GE Q-line branch circuit breakers. material: Copper bus (tin plated), Galvanized box

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDF1TQC163200E0019---DET223D.pdfData sheet
ABB 1TQC163200E0019 - DET223D cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
ABB
Catalog no.
1TQC163200E0019 - DET223D
Product type
—
MasterFormat
26
Cut sheet
PDF · manufacturer current

Product details

Catalog number1TQC163200E0019 - DET223D
DescriptionABB Riser panel (PowerMark Gold). Model 1TQC163200E0019. Single-phase, 125A and 200A; 12, 20, and 40 circuits; 4 5/8" gutter for tap kits; Accepts GE Q-line branch circuit breakers. material: Copper bus (tin plated), Galvanized box
MountingRiser
Compliance22kAIC
Voltage125A, 200A.

Also cataloged as: PowerMark Gold Riser panels, TLM2012CCURP, TLM1212CCURP, TLM4020CCURP, TLM4020CCURPW, THLK3225, TMAGB24, TMAGB33, TMAGB39, TMAGB43, TMAGB43D
