ABBPowerMark Gold Meter Socket Load Centers - 125-200 amp, 4 circuit1TQC183200E0003 - DET427A

ABB Meter Socket Load Center (Meter Socket Load Centers). Model TSMR412CSCU, TSMR415CSCU, TSMR420CSCU. 125-200 Amp Main Rating; 4 Circuit Capacity; 22 kAIC Interrupting Rating; NEMA 3R Outdoor Enclosure. mounting: Combination flush/surface type

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDF1TQC183200E0003---DET427A.pdfData sheet
ABB 1TQC183200E0003 - DET427A cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
ABB
Catalog no.
1TQC183200E0003 - DET427A
Product type
—
MasterFormat
26
Cut sheet
PDF · manufacturer current

Product details

Catalog number1TQC183200E0003 - DET427A
DescriptionABB Meter Socket Load Center (Meter Socket Load Centers). Model TSMR412CSCU, TSMR415CSCU, TSMR420CSCU. 125-200 Amp Main Rating; 4 Circuit Capacity; 22 kAIC Interrupting Rating; NEMA 3R Outdoor Enclosure. mounting: Combination flush/surface type
Dimensions14 9/16" W x 33 9/16" H x 6 3/16" D
ComplianceUL Listed (UL 67), EUSERC
Voltage120/240 VAC.

Also cataloged as: TSMR, TSMR412CSCU, TSMR415CSCU, TSMR420CSCU, TSMR-412CSCU, TSMR-415CSCU, TSMR-420CSCU
