Ames Fire & WaterworksLFC500LFC500
Ames Fire & Waterworks Reduced Pressure Detector Assembly. Model LFC500. Consists of two independent Link Check modules and a differential pressure relief valve; Features a flood sensor on the relief valve for detecting excessive water discharge; Includes a metered bypass to detect leakage or theft of water; OS&Y model includes an option for integrated supervisory switches on gate valves. material: Type 304 (Schedule 40) stainless steel housing and sleeve; Lead Free bronze body
Free to start · No card required · The agent pulls this cut sheet in automatically
- Manufacturer
- Ames Fire & Waterworks
- Catalog no.
- LFC500
- Product type
- Plumbing
- MasterFormat
- 21
- Cut sheet
- PDF · manufacturer current
Product details
| Catalog number | LFC500 |
|---|---|
| Description | Ames Fire & Waterworks Reduced Pressure Detector Assembly. Model LFC500. Consists of two independent Link Check modules and a differential pressure relief valve; Features a flood sensor on the relief valve for detecting excessive water discharge; Includes a metered bypass to detect leakage or theft of water; OS&Y model includes an option for integrated supervisory switches on gate valves. material: Type 304 (Schedule 40) stainless steel housing and sleeve; Lead Free bronze body |
| Connection size | 2.5" – 10" |
| End connection | Groove fittings |
| Mounting | Horizontal, Z pattern horizontal, N pattern ho |
Also cataloged as: LFC500N-OSY, LFC500-OSY, LFC500N, LFC500Z, LFC500NBFG, LFC500ZBFG, LFC500-N, LFC500-Z, LFC500--OSY, LFC500-BFG, LFC500--TS-OSY, LFC500-FS, LFC500-TS-OSY, LFC500-OSY FxG, LFC500-OSY GxF, LFC500-OSY GxG
