Carrier50ZHB

Carrier Duct Transition Kit (Ductwork). Model CPDUCFLG003A00. Part is not available for order; drawings are for field-fabricated transition; Requires 14 in. round duct flange (field supplied); Approximate blank size 16-1/8 x 22-1/8 in.; Material is 22-24 ga. G90 galvanized steel. material: 22-24 ga. G90 galvanized steel

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDF50ZHB.pdfData sheet
Carrier 50ZHB cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Carrier
Catalog no.
50ZHB
Product type
HVAC
MasterFormat
23
Cut sheet
PDF · manufacturer current

Product details

Catalog number50ZHB
DescriptionCarrier Duct Transition Kit (Ductwork). Model CPDUCFLG003A00. Part is not available for order; drawings are for field-fabricated transition; Requires 14 in. round duct flange (field supplied); Approximate blank size 16-1/8 x 22-1/8 in.; Material is 22-24 ga. G90 galvanized steel. material: 22-24 ga. G90 galvanized steel
Connection size14 in. round
End connectionRound duct flange
FinishGalvanized
MountingField-fabricated
Dimensions20 3/16 in. x 10 1/8 in. x 7 3/4 in.
