DIV 23 · HVACHVACCUT SHEET INDEXED

CarrierMMD4

Carrier High Static Ducted Indoor Unit (Mini-Split Air Conditioner). Model MMD-AP0726HP-UL / MMD-AP0966HP-UL. Cooling Capacity: 72 kBtu/h (0726) / 96 kBtu/h (0966)

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFMMD4.pdfData sheet
Carrier MMD4 cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Carrier
Catalog no.
MMD4
Product type
HVAC
MasterFormat
23
Cut sheet
PDF · manufacturer current

Product details

Catalog numberMMD4
DescriptionCarrier High Static Ducted Indoor Unit (Mini-Split Air Conditioner). Model MMD-AP0726HP-UL / MMD-AP0966HP-UL. Cooling Capacity: 72 kBtu/h (0726) / 96 kBtu/h (0966)
Heating Capacity81 kBtu/h (0726) / 108 kBtu/h (0966)
Fan TypeCentrifugal fan
Unit Weight218 lbs. material: Zinc hot dipping steel plate
Connection sizeGas 7/8", Liquid 1/2"
End connectionField supply air filter
Pressure RatingExternal static pressure range 0.201 - 1.005 in WG
Flow Rate2236 cfm (0726) / 2825 cfm (0966)
MountingDucted.
