DIV 23 · HVACHVACCUT SHEET INDEXED

Carrieri-Vu Open VAV Zone II Secondary TerminalOPN-B3-P-02

Carrier VAV Zone II Secondary Terminal Controller (Carrier i-Vu Building Automation System). Model OPN-SECTRM-02. Controls secondary zone damper with CFM measurement; Features separable brushless DC actuator with 45 in-lb torque; Integral precision differential pressure sensor (0-2 in. H2O); Connects via ACTnet bus to Carrier ZoneCtrl II. connectionSize: 3/16 in. (4.75 mm) I.D. tubing

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFOPN-B3-P-02.pdfData sheet
Carrier OPN-B3-P-02 cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Carrier
Catalog no.
OPN-B3-P-02
Product type
HVAC
MasterFormat
23
Cut sheet
PDF · manufacturer current

Product details

Catalog numberOPN-B3-P-02
DescriptionCarrier VAV Zone II Secondary Terminal Controller (Carrier i-Vu Building Automation System). Model OPN-SECTRM-02. Controls secondary zone damper with CFM measurement; Features separable brushless DC actuator with 45 in-lb torque; Integral precision differential pressure sensor (0-2 in. H2O); Connects via ACTnet bus to Carrier ZoneCtrl II. connectionSize: 3/16 in. (4.75 mm) I.D. tubing
End connectionBarbed tapered airflow connections
Pressure Rating0–2 in. H2O
MountingSeparable actuator
ComplianceUL Listed File E143900, FCC Class A, CE Mark, RoHS Compliant.
