Daikind07500960-Data-Sheet-Connector750-960

Daikin PROFIBUS Fieldbus Connector (Fieldbus Connector). Model 750-960. Data transmission rate up to 12 Mbits/s; Degree of protection IP20; Ambient operating temperature 0°C ... +60°C; Max. current consumption 5 mA. material: PA66-105-V2

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDF750-960.pdfData sheet
Daikin 750-960 cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Daikin
Catalog no.
750-960
Product type
HVAC
MasterFormat
23
Cut sheet
PDF · manufacturer current

Product details

Catalog number750-960
DescriptionDaikin PROFIBUS Fieldbus Connector (Fieldbus Connector). Model 750-960. Data transmission rate up to 12 Mbits/s; Degree of protection IP20; Ambient operating temperature 0°C ... +60°C; Max. current consumption 5 mA. material: PA66-105-V2
Connection sizeD-Sub male connector; 9 poles
End connectionCAGE CLAMP® terminal strip
Finishlight gray
MountingFixing screw UNC-2 A 4-40
Dimensions54 mm x 36 mm x 16 mm.
