DIV 23 · HVACHVACCUT SHEET INDEXED

DaikinSDS-DC_CHPF3642D6CHPF1824A6

Daikin Cased Horizontal Evaporator Coil (Evaporator Coil). Model CHPF3642D6. 3.5 Ton capacity; 42,000 Btu/hr nominal cooling capacity; Optimized for R-410A refrigerant; 21" depth for easier attic access. material: All-Aluminum

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFCHPF1824A6.pdfData sheet
Daikin CHPF1824A6 cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Daikin
Catalog no.
CHPF1824A6
Product type
HVAC
MasterFormat
23
Cut sheet
PDF · manufacturer current

Product details

Catalog numberCHPF1824A6
DescriptionDaikin Cased Horizontal Evaporator Coil (Evaporator Coil). Model CHPF3642D6. 3.5 Ton capacity; 42,000 Btu/hr nominal cooling capacity; Optimized for R-410A refrigerant; 21" depth for easier attic access. material: All-Aluminum
Connection size7/8" Suction, 3/8" Liquid, 3/4" Condensate
FinishGalvanized, leather grain-embossed
MountingHorizontal
Dimensions24-1/2 x 21-1/8 x 21 in
ComplianceAHRI certified, ETL listed.

Also cataloged as: CHPF2430B6, CHPF3636B6, CHPF3642C6, CHPF3642D6, CHPF3743C6, CHPF3743D6, CHPF4860D6, CHPF-1824, CHPF-2430, CHPF-3636, CHPF-3642, CHPF-3743, CHPF-4860, CHPF-A6, CHPF-B6, CHPF-C6, CHPF-D6
