DaikinDAQ09034DAQ09034
Daikin Light Commercial Air Handler (Air Handling Unit). Model DAQ09034. 7.5 Ton capacity; 90,000 Btu/hr nominal cooling; R-32 refrigerant; Two 5-speed direct-drive motors. material: Galvanized-steel cabinet, Copper tube/aluminum fin coils
Free to start · No card required · The agent pulls this cut sheet in automatically
- Manufacturer
- Daikin
- Catalog no.
- DAQ09034
- Product type
- HVAC
- MasterFormat
- 23
- Cut sheet
- PDF · manufacturer current
Product details
| Catalog number | DAQ09034 |
|---|---|
| Description | Daikin Light Commercial Air Handler (Air Handling Unit). Model DAQ09034. 7.5 Ton capacity; 90,000 Btu/hr nominal cooling; R-32 refrigerant; Two 5-speed direct-drive motors. material: Galvanized-steel cabinet, Copper tube/aluminum fin coils |
| Connection size | Suction 1-1/8 in, Liquid 5/8 in, Condensate 3/4 in |
| Dimensions | 24.1875 x 60.46875 x 48.09375 in (HxWxD) |
| Compliance | AHRI Certified, ETL Listed |
| Voltage | 460V 3PH. |
