DaikinSDS-Submittal_FWXT05AATSBUCRFWXT03AATSBUCL

Daikin Heat Pump Convector (Daikin ALTHERMA). Model FWXT05AATSBUCR. Nominal capacities of 3,000 / 5,000 / 7,000 Btu/h; Sound pressure level down to 25 dBA; Integrated thermostat and fully modulating controller; Compatible with Daikin ALTHERMA 3 H HT heat pump system. material: Metal Sheet

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFFWXT03AATSBUCL.pdfData sheet
Daikin FWXT03AATSBUCL cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Daikin
Catalog no.
FWXT03AATSBUCL
Product type
HVAC
MasterFormat
23
Cut sheet
PDF · manufacturer current

Product details

Catalog numberFWXT03AATSBUCL
DescriptionDaikin Heat Pump Convector (Daikin ALTHERMA). Model FWXT05AATSBUCR. Nominal capacities of 3,000 / 5,000 / 7,000 Btu/h; Sound pressure level down to 25 dBA; Integrated thermostat and fully modulating controller; Compatible with Daikin ALTHERMA 3 H HT heat pump system. material: Metal Sheet
End connectionLeft or right-hand side
Pressure Rating145 psi
Flow Rate3.88-9.75 ft³/h (Cooling), 4.94-12.50 ft³/h (Heating)
FinishWhite, RAL 9003
MountingWall-mounted.

Also cataloged as: FWXT03AATSBUCR, FWXT05AATSBUCL, FWXT05AATSBUCR, FWXT07AATSBUCL, FWXT07AATSBUCR, FWXT-03AATSBUC, FWXT-05AATSBUC, FWXT-07AATSBUC
