NIBCOH-2244x_Zspec

NIBCO Gas Ball Valve with Sediment Trap (Gas Valve). Model H-2244x. Full port forged brass body; Includes 3" Tee Fitting & Cap; PTFE seats and packing; Max operating temperature 149°F. material: Forged Brass

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFH-2244x_Zspec.pdfData sheet
NIBCO H-2244x_Zspec cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
NIBCO
Catalog no.
H-2244x_Zspec
Product type
Plumbing/Valves
MasterFormat
22
Cut sheet
PDF · manufacturer current

Product details

Catalog numberH-2244x_Zspec
DescriptionNIBCO Gas Ball Valve with Sediment Trap (Gas Valve). Model H-2244x. Full port forged brass body; Includes 3" Tee Fitting & Cap; PTFE seats and packing; Max operating temperature 149°F. material: Forged Brass
Connection size1/2" or 3/4"
End connectionFIP
Pressure Rating1/2 PSI Max
DimensionsVaries by model (e.g., H-22442: A=0.50, B=1.44, C=1.28, D=1.12, E=2.20, F=2.99, G=8.86)
ComplianceANSI Z21.15, CSA 9.1, ASME B1.20.1.
