NIBCOH-4064_ZSpec

NIBCO 3 Way L-Port Ball Valve (Ball Valves). Model 4064 Series. Full Port Forged Brass Body; 3 Way L-Port with Reversible Handle; Blowout Proof Stem; PTFE Seat and Stem Seal. material: Forged Brass

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFH-4064_ZSpec.pdfData sheet
NIBCO H-4064_ZSpec cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
NIBCO
Catalog no.
H-4064_ZSpec
Product type
Plumbing/Valves
MasterFormat
22
Cut sheet
PDF · manufacturer current

Product details

Catalog numberH-4064_ZSpec
DescriptionNIBCO 3 Way L-Port Ball Valve (Ball Valves). Model 4064 Series. Full Port Forged Brass Body; 3 Way L-Port with Reversible Handle; Blowout Proof Stem; PTFE Seat and Stem Seal. material: Forged Brass
Connection size1/2", 3/4", 1"
End connectionIPS
Pressure Rating600 WOG / 150 WSP
Flow RateCv 10.8 (1/2"), 26.8 (3/4"), 47.4 (1")
DimensionsA: 1/2"-1", B: 2 1/8"-2 15/16", C: 1 3/4"-2 3/8", D: 3 1/4"-4 5/8", E: 1"-1 7/16", F: 1 11/16"-2 7/16".
