DIV 22 · PLUMBINGPLUMBING/VALVESCUT SHEET INDEXED
NIBCOH-7-7x20-C7_ZSpec
NIBCO Thermostatic Mixing Valve. Model H-TMV-230F. Max Input Temperature: 230°F
Free to start · No card required · The agent pulls this cut sheet in automatically
- Manufacturer
- NIBCO
- Catalog no.
- H-7-7x20-C7_ZSpec
- Product type
- Plumbing/Valves
- MasterFormat
- 22
- Cut sheet
- PDF · manufacturer current
Product details
| Catalog number | H-7-7x20-C7_ZSpec |
|---|---|
| Description | NIBCO Thermostatic Mixing Valve. Model H-TMV-230F. Max Input Temperature: 230°F |
| Outlet Temperature Range | 104°F - 176°F; Includes Integral Check Valves; Lead-Free Certified. material: Forged Brass |
| Connection size | 1/2", 3/4", 1" |
| End connection | FIP, MIP, SWT, Press |
| Pressure Rating | 150 PSI CWP Max |
| Dimensions | Varies by size (e.g., 1/2" FIP: 5.50" x 6.25") |
| Compliance | NSF/ANSI 61, NSF/ANSI 372, ASSE 1017, CSA B125.3. |
