NIBCOH-9061_ZSpec
NIBCO Full Port Forged Brass Ball Valve (Ball Valve). Model 9061W Series. Full Port design with Hi-Flow Hose Drain; Adjustable Packing Gland & Reversible Handle; Lead Free certified; Body and End Caps made of Brass with PP-R. material: Forged Brass, PP-R, PTFE
Free to start · No card required · The agent pulls this cut sheet in automatically
- Manufacturer
- NIBCO
- Catalog no.
- H-9061_ZSpec
- Product type
- Plumbing/Valves
- MasterFormat
- 22
- Cut sheet
- PDF · manufacturer current
Product details
| Catalog number | H-9061_ZSpec |
|---|---|
| Description | NIBCO Full Port Forged Brass Ball Valve (Ball Valve). Model 9061W Series. Full Port design with Hi-Flow Hose Drain; Adjustable Packing Gland & Reversible Handle; Lead Free certified; Body and End Caps made of Brass with PP-R. material: Forged Brass, PP-R, PTFE |
| Connection size | 25mm to 63mm (3/4" to 2") |
| End connection | Female PP-R Metric Socket |
| Pressure Rating | 355 PSI @ 73°F |
| Compliance | NSF/ANSI 61, NSF/ANSI 372. |
