NIBCOH-x053_ZSpec
NIBCO Full Port Forged Brass Ball Valve (Ball Valve). Model H-x053W Series. Full port design with adjustable packing gland; Reversible handle with steel CP finish; Blowout proof stem; PTFE seats and stem seal. material: Forged Brass
Free to start · No card required · The agent pulls this cut sheet in automatically
- Manufacturer
- NIBCO
- Catalog no.
- H-x053_ZSpec
- Product type
- Plumbing/Valves
- MasterFormat
- 22
- Cut sheet
- PDF · manufacturer current
Product details
| Catalog number | H-x053_ZSpec |
|---|---|
| Description | NIBCO Full Port Forged Brass Ball Valve (Ball Valve). Model H-x053W Series. Full port design with adjustable packing gland; Reversible handle with steel CP finish; Blowout proof stem; PTFE seats and stem seal. material: Forged Brass |
| Connection size | 1/4" to 1" |
| End connection | MIP x FIP |
| Pressure Rating | 600 WOG / 150 WSP |
| Flow Rate | Cv 7.8 to 49.3 |
| Dimensions | A: 1/4" to 1", B: 2 1/16" to 3", C: 1 5/8" to 2 1/2", D: 3 1/2" to 4 7/16". |
