DIV 22 · PLUMBINGPLUMBING/VALVESCUT SHEET INDEXED

NIBCOH-x170_ZSpec

NIBCO Full Port Forged Brass Ball Valve (H-x070 Series). Model H-x170_ZSpec. Full port design; Adjustable packing gland; Blowout proof stem; PTFE ball seats and stem packing. material: Forged Brass

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFH-x170_ZSpec.pdfData sheet
NIBCO H-x170_ZSpec cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
NIBCO
Catalog no.
H-x170_ZSpec
Product type
Plumbing/Valves
MasterFormat
22
Cut sheet
PDF · manufacturer current

Product details

Catalog numberH-x170_ZSpec
DescriptionNIBCO Full Port Forged Brass Ball Valve (H-x070 Series). Model H-x170_ZSpec. Full port design; Adjustable packing gland; Blowout proof stem; PTFE ball seats and stem packing. material: Forged Brass
Connection size1/2" to 2" (FIP), 1/2" to 1" (SWT)
End connectionFIP, SWT
Pressure Rating600 PSI CWP MAX
DimensionsVaries by size (e.g., 1/2" FIP: A=2.05, B=1.94, C=3.54)
ComplianceANSI Z21.15/CSA 9.1, ANSI B1.20.1.
