DIV 22 · PLUMBINGPLUMBING/VALVESCUT SHEET INDEXED

NIBCOH-x172_ZSpec

NIBCO Full Port Forged Brass Ball Valve (Ball Valves). Model 4172 Series. Full port design with 1/4" threaded gauge hole (plugged); Reversible handle with steel CP finish; Blowout proof stem with adjustable packing gland; PTFE seats and stem seal. material: Forged Brass

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFH-x172_ZSpec.pdfData sheet
NIBCO H-x172_ZSpec cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
NIBCO
Catalog no.
H-x172_ZSpec
Product type
Plumbing/Valves
MasterFormat
22
Cut sheet
PDF · manufacturer current

Product details

Catalog numberH-x172_ZSpec
DescriptionNIBCO Full Port Forged Brass Ball Valve (Ball Valves). Model 4172 Series. Full port design with 1/4" threaded gauge hole (plugged); Reversible handle with steel CP finish; Blowout proof stem with adjustable packing gland; PTFE seats and stem seal. material: Forged Brass
Connection size1/2" to 2" IPS
End connectionThreaded (ANSI B1.20.1)
Pressure Rating600 WOG / 150 WSP
Flow RateCv 11.5 to 248.7
DimensionsA: 1/2" to 2", B: 2 5/16" to 4 5/8", C: 2 1/16" to 4 1/8", D: 3 7/16" to 6 1/2".
