nVent HOFFMANarf05030r5-englishARF05030R5
nVent HOFFMAN Rain hood (Wall Mounted Enclosures). Model ARF05030R5. Weight: 3.6 kg; Roof is slightly sloped with a dripstrip; Increases enclosure dimensions by H:60 mm, D:20 mm, W:20 mm; Machining is required for installation. material: 1.5 mm mild steel
Free to start · No card required · The agent pulls this cut sheet in automatically
- Manufacturer
- nVent HOFFMAN
- Catalog no.
- ARF05030R5
- Product type
- Electrical
- MasterFormat
- 26
- Cut sheet
- PDF · manufacturer current
Product details
| Catalog number | ARF05030R5 |
|---|---|
| Description | nVent HOFFMAN Rain hood (Wall Mounted Enclosures). Model ARF05030R5. Weight: 3.6 kg; Roof is slightly sloped with a dripstrip; Increases enclosure dimensions by H:60 mm, D:20 mm, W:20 mm; Machining is required for installation. material: 1.5 mm mild steel |
| Finish | RAL 7035 structured powder coating |
| Mounting | Outdoor shelter for single mounted enclosures |
| Dimensions | W: 500 mm, D: 300 mm. |
- Official cut sheet, indexed
