TraneINTELLICORE CA COMPONENT LOCATION CONTROL BOX12134884C

Trane Component Location Control Box (HVAC Controls). Model INTELLICORE CA. Controls transformer protection fuses: 25A (200V), 20A (230V), 12A (380/415V), 8A (460/575V); Condenser motor circuit protection: 30A Class CC Time Delay for 20T-80T units; Condenser motor circuit protection: 35A Class J Time Delay for 100T/120T units at 200/230V; Controls circuit switch rating: 20A Class CC Time Delay. voltage: 200V, 230V, 380V, 415V, 460V, 575V.

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDF12134884C.pdfData sheet
Trane 12134884C cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Trane
Catalog no.
12134884C
Product type
HVAC
MasterFormat
23
Cut sheet
PDF · manufacturer current

Product details

Catalog number12134884C
DescriptionTrane Component Location Control Box (HVAC Controls). Model INTELLICORE CA. Controls transformer protection fuses: 25A (200V), 20A (230V), 12A (380/415V), 8A (460/575V); Condenser motor circuit protection: 30A Class CC Time Delay for 20T-80T units; Condenser motor circuit protection: 35A Class J Time Delay for 100T/120T units at 200/230V; Controls circuit switch rating: 20A Class CC Time Delay. voltage: 200V, 230V, 380V, 415V, 460V, 575V.
