Trane Power Distribution and Compressor Power Circuit Diagram (HVAC Electrical Schematic). Model Trane V Frame CGAM Refresh. Applies to Trane V Frame CGAM units; Covers Compressor Power Circuit 1 (Lines 1-75); Requires copper conductors with 90C insulation rating; Includes optional Electronic Protection Module for 20-30 ton compressors. material: Copper conductors
