TraneBAS-SVN096B-EN
Trane Key Lock Assembly (HVAC Enclosure Accessories). Model S3090070262. Compatible with Tracer Large Enclosure models X13651552-01 through X13651555-01; Includes one key lock assembly and two keys; Requires Phillips screw driver (no. 2) for installation; Installation involves ring nut, screw, and cam. mounting: Enclosure Door
Free to start · No card required · The agent pulls this cut sheet in automatically
- Manufacturer
- Trane
- Catalog no.
- BAS-SVN096B-EN
- Product type
- HVAC
- MasterFormat
- 23
- Cut sheet
- PDF · manufacturer current
Product details
| Catalog number | BAS-SVN096B-EN |
|---|---|
| Description | Trane Key Lock Assembly (HVAC Enclosure Accessories). Model S3090070262. Compatible with Tracer Large Enclosure models X13651552-01 through X13651555-01; Includes one key lock assembly and two keys; Requires Phillips screw driver (no. 2) for installation; Installation involves ring nut, screw, and cam. mounting: Enclosure Door |
| Voltage | 120 VAC / 230 VAC. |
