DIV 22 · PLUMBINGPLUMBINGCUT SHEET INDEXED

ZurnZ189 — Z189 Roof Scupper DrainZ189

Name: Zurn Z189 — Z189 Roof Scupper Drain
Brand: Zurn
SKU: Z189

Zurn Roof Scupper Drain (Drainage). Model Z189. Approx. Grate Open Area: 18 [8] sq. in. [cm2]

Free to start · No card required · The agent pulls this cut sheet in automatically

Product details

Catalog number	Z189
Description	Zurn Roof Scupper Drain (Drainage). Model Z189. Approx. Grate Open Area: 18 [8] sq. in. [cm2]
Weight	20 [129] lbs. [kg]
Outlet Options	Threaded (IP) or No-Hub (NH)
Grate Options	Aluminum, Polished Bronze, or Polished Nickel Bronze. material: Dura-Coated cast iron body, aluminum strainer
Connection size	2, 3, 4 [51, 76, 102]
End connection	45° outlet, Threaded or No-Hub
Finish	Dura-Coated, Aluminum, Polished Bronze, or Polished Nickel Bronze
Mounting	Flush type with membrane flashing clamp
Dimensions	4-3/4" x 6-1/2" x 11 [121mm x 165mm x 279mm].
