ZurnZ451B

Zurn Shallow Trap Floor Drain (Floor Drain). Model Z451B. Shallow trap design with 2 or 3 inch waterway; Adjustable 'Type B' polished nickel bronze heel-proof strainer; Dura-Coated cast iron body with bottom outlet; Includes combination invertible membrane clamp and adjustable collar. material: Dura-Coated cast iron body, nickel bronze strainer

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFZ451B.pdfData sheet
Zurn Z451B cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Zurn
Catalog no.
Z451B
Product type
Plumbing
MasterFormat
22
Cut sheet
PDF · manufacturer current

Product details

Catalog numberZ451B
DescriptionZurn Shallow Trap Floor Drain (Floor Drain). Model Z451B. Shallow trap design with 2 or 3 inch waterway; Adjustable 'Type B' polished nickel bronze heel-proof strainer; Dura-Coated cast iron body with bottom outlet; Includes combination invertible membrane clamp and adjustable collar. material: Dura-Coated cast iron body, nickel bronze strainer
Connection size2-3 [51-76] waterway
End connectionThreaded side outlet
FinishPolished Nickel Bronze
MountingCombination invertible membrane clamp and adjustable collar
DimensionsStrainer Dia 5-8 [127-203] in.
