DIV 22 · PLUMBINGPLUMBINGCUT SHEET INDEXED

ZurnZ9A-PHIX — Zurn Z9AZ9A-PHIX

Zurn Cartridge Acid Neutralization System (Acid Neutralization System). Model Z9A-PHIX. Maximum flow rate of 8 GPM [36 LPM]; Includes removable upper neutralization chamber and lower sediment collection chamber; Uses PHIX® Media (non-hazardous solid alkali non-resin materials); Replaces standard P-trap and downstream acid waste piping. material: Glass-filled polypropylene

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFZ9A-PHIX.pdfData sheet
Zurn Z9A-PHIX cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Zurn
Catalog no.
Z9A-PHIX
Product type
Plumbing
MasterFormat
22
Cut sheet
PDF · manufacturer current

Product details

Catalog numberZ9A-PHIX
DescriptionZurn Cartridge Acid Neutralization System (Acid Neutralization System). Model Z9A-PHIX. Maximum flow rate of 8 GPM [36 LPM]; Includes removable upper neutralization chamber and lower sediment collection chamber; Uses PHIX® Media (non-hazardous solid alkali non-resin materials); Replaces standard P-trap and downstream acid waste piping. material: Glass-filled polypropylene
Connection size1-1/2" [38mm]
End connectionCompression fitting inlet, No-Hub outlet
Flow Rate8 GPM [36 LPM]
MountingPoint of use, replaces standard P-trap
Dimensions14-1/4" [362] H x 9" [229] W x 5-1/2" [140] D.
