DIV 22 · PLUMBINGPLUMBINGCUT SHEET INDEXED

ZurnZW209H

Name: Zurn ZW209H
Brand: Zurn
SKU: ZW209H

Zurn Pressure Reducing and Pressure Sustaining Valve. Model ZW209H. Minimum inlet pressure 10 PSI

Free to start · No card required · The agent pulls this cut sheet in automatically

Product details

Catalog number	ZW209H
Description	Zurn Pressure Reducing and Pressure Sustaining Valve. Model ZW209H. Minimum inlet pressure 10 PSI
Temperature rating	Water 33°F to 140°F
Pilot spring range	15-120 psi (Pressure Reducing), 50-200 psi (Pressure Sustaining); Includes isolation valves and pressure gauges. material: Ductile Iron ASTM A536, Stainless Steel, Buna-N Rubber, Nylon Reinforced Buna-N
Connection size	1 1/4"-16"
End connection	Threaded, Flanged, Grooved
Pressure Rating	400 psi max (Threaded), 250 psi max (ANSI Class 150 Flanged), 400 psi max (ANSI Class 300 Flanged), 300 psi max (Grooved)
Finish	Blue Epoxy Coated
