DIV 09 · FINISHESACOUSTICAL CEILINGSCUT SHEET INDEXED

USGDonn® Brand ZXLA™ Suspension SystemAC3029

USG Acoustical Suspension System (Ceiling Suspension System). Model ZXLA. Conforms to ASTM C635; Fire-rated assemblies up to two hours; Tested for exterior wind-uplift applications; Rated loads up to 16 lb./LF for Heavy Duty. material: G90 hot-dipped galvanized steel body with aluminum cap

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFAC3029.pdfData sheet
USG AC3029 cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
USG
Catalog no.
AC3029
Product type
Acoustical Ceilings
MasterFormat
09 51 13
Cut sheet
PDF · manufacturer current

Product details

Catalog numberAC3029
DescriptionUSG Acoustical Suspension System (Ceiling Suspension System). Model ZXLA. Conforms to ASTM C635; Fire-rated assemblies up to two hours; Tested for exterior wind-uplift applications; Rated loads up to 16 lb./LF for Heavy Duty. material: G90 hot-dipped galvanized steel body with aluminum cap
Connection size15/16" Tee System
End connectionQuick-Release cross tees
FinishPolyester paint, Powder-coated
MountingHanger spacing 4', 5', 6'
Dimensions12' Length, 1.64" Height.
