DIV 23 · HVACDAMPERSCUT SHEET INDEXED

Greenheckfsd-211m modulating combination fire smoke damperfsd-211m

Name: Greenheck fsd-211m modulating combination fire smoke damper
Brand: Greenheck
SKU: fsd-211m

Greenheck Modulating Combination Fire Smoke Damper (Fire and Smoke Dampers). Model FSD-211M. Fire Rating: 1.5 hours

Free to start · No card required · The agent pulls this cut sheet in automatically

Product details

Catalog number	fsd-211m
Description	Greenheck Modulating Combination Fire Smoke Damper (Fire and Smoke Dampers). Model FSD-211M. Fire Rating: 1.5 hours
Leakage Class	I
Blade Type	3V Parallel
Closure Temperature	165°F (74°C) standard, 212°F (100°C) optional. material: Galvanized steel frame and blades (16 ga.), 316SS axle bearings
Connection size	Min 6x6 in (102x102 mm), Max Single 36x36 in (914x914 mm), Max Multiple 72x72 in (1829x1829 mm)
End connection	Vertical or Horizontal mounting
Pressure Rating	Up to 4 in. wg (1 kPa)
Flow Rate	Up to 2000 fpm (10.2 m/s)
Finish	Galvanized.
