Greenheckvcd-23v control dampervcd-23v
Greenheck Low Leakage 3V Control Damper (Control Damper). Model VCD-23V. Leakage rating of 3 cfm/ft2 at 1 in. wg (55 cmh/m2 at .25 kPa) or less; Temperature range -40°F to 250°F (-40°C to 121°C); Blade type 3V with opposed or parallel action; Blade seals made of TPE (Standard) or Silicone (Optional). material: Galvanized Steel (Standard), 304SS (Optional)
Free to start · No card required · The agent pulls this cut sheet in automatically
- Manufacturer
- Greenheck
- Catalog no.
- vcd-23v
- Product type
- Dampers
- MasterFormat
- 23
- Cut sheet
- PDF · manufacturer current
Product details
| Catalog number | vcd-23v |
|---|---|
| Description | Greenheck Low Leakage 3V Control Damper (Control Damper). Model VCD-23V. Leakage rating of 3 cfm/ft2 at 1 in. wg (55 cmh/m2 at .25 kPa) or less; Temperature range -40°F to 250°F (-40°C to 121°C); Blade type 3V with opposed or parallel action; Blade seals made of TPE (Standard) or Silicone (Optional). material: Galvanized Steel (Standard), 304SS (Optional) |
| Connection size | Min 6x6 in (152x152 mm), Max 148x96 in (3759x2438 mm) |
| End connection | 5 in x 1 in hat channel frame (Standard), Single/Reversed/Double flange (Optional) |
| Pressure Rating | Up to 5 in. wg (1.2 kPa) |
| Flow Rate | Up to 3000 fpm (15. |
