Greenheckvcd-43 control dampervcd-43
Greenheck Control Damper (HVAC Dampers). Model VCD-43. Low leakage damper with opposed or parallel airfoil blades; Leakage rating of 3 cfm/ft² at 1 in. wg (55 cmh/m² at .25 kPa) or less; Temperature range -40°F to 250°F (-40°C to 121°C); Blade seals made of TPE (standard) or Silicone (optional). material: Extruded Aluminum (6063T5) frame and blades
Free to start · No card required · The agent pulls this cut sheet in automatically
- Manufacturer
- Greenheck
- Catalog no.
- vcd-43
- Product type
- Dampers
- MasterFormat
- 23
- Cut sheet
- PDF · manufacturer current
Product details
| Catalog number | vcd-43 |
|---|---|
| Description | Greenheck Control Damper (HVAC Dampers). Model VCD-43. Low leakage damper with opposed or parallel airfoil blades; Leakage rating of 3 cfm/ft² at 1 in. wg (55 cmh/m² at .25 kPa) or less; Temperature range -40°F to 250°F (-40°C to 121°C); Blade seals made of TPE (standard) or Silicone (optional). material: Extruded Aluminum (6063T5) frame and blades |
| Connection size | Min 8x6 in (203x178 mm), Max 60x78 in (1524x1981 mm) single section |
| End connection | 5 in. x 1 in. hat channel (127 mm x 25 mm) |
| Pressure Rating | Up to 8 in. wg (2 kPa) differential |
| Flow Rate | Up to 6000 fpm (30.5 m/s) velocity; finis |
- Official cut sheet, indexed
