DIV 27 · COMMUNICATIONSCOMMUNICATIONSCUT SHEET INDEXED

PanduitIndustrialNet™ Category 6A S/FTP Copper CableCOSP444--SA-ENG

Panduit Category 6A S/FTP Copper Cable (Industrial Ethernet Cable). Model COSP444--SA-ENG. Supports frequencies up to 500 MHz; Certified performance up to 80 meters

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFCOSP444--SA-ENG.pdfData sheet
Panduit COSP444--SA-ENG cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Panduit
Catalog no.
COSP444--SA-ENG
Product type
Communications
MasterFormat
27
Cut sheet
PDF · manufacturer current

Product details

Catalog numberCOSP444--SA-ENG
DescriptionPanduit Category 6A S/FTP Copper Cable (Industrial Ethernet Cable). Model COSP444--SA-ENG. Supports frequencies up to 500 MHz; Certified performance up to 80 meters
Temperature rating-40°C to 80°C
Flex life1 million cycles at 10x cable diameter. material: Stranded copper conductors, foamed polyethylene insulation, polyurethane (PUR) jacket
Connection size24/7 AWG
FinishFlame retardant, halogen-free
Dimensions8.0mm (0.315 in.) nominal diameter
ComplianceIEC 61156-6, ANSI/TIA-568-C.2, IEC 60332-1, IEC 60754-1/-2, IEC 61034-2, EN50575.
