DIV 27 · COMMUNICATIONSCOMMUNICATIONSCUT SHEET INDEXED

PanduitToolCT-2940

Name: Panduit Tool (CT-2940)
Brand: Panduit
SKU: CT-2940

Panduit Battery operated hydraulic crimping tool (Hydraulic Crimping Tool). Model CT-2940/STBT. Output force: 15 tons (135 kN)

Free to start · No card required · The agent pulls this cut sheet in automatically

Product details

Catalog number	CT-2940
Description	Panduit Battery operated hydraulic crimping tool (Hydraulic Crimping Tool). Model CT-2940/STBT. Output force: 15 tons (135 kN)
Battery	18.0 VDC 4 Ah Lithium-Ion
Lifetime performance	20,000 cycles minimum
Weight	17.6 lbs (8.0 kg). connectionSize: #8 AWG – 1000 MCM Copper; #6 AWG – 1000 MCM Aluminum
End connection	Compression connectors
Pressure Rating	15 tons (135 kN)
Finish	Black housing
Mounting	Handheld
Dimensions	19.5" L x 3.1" W x 13" H (496 x 78 x 331 mm).
