DIV 27 · COMMUNICATIONSCOMMUNICATIONSCUT SHEET INDEXED

PanduitFBAS34-WW-ENG

Panduit Indoor-Outdoor Ribbon Cable (Optical Fiber Cable). Model FBAS34-WW-ENG. Singlemode fibers (ITU G.657.A2/B2); Attenuation max 0.4dB/km at 1310nm and 0.3dB/km at 1550nm; Maximum tensile rating 600 lb (2670 N); Installation temperature range -4°F to +140°F (-20°C to +60°C). material: All-dielectric, LSZH, OFNR, EuroClass

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFFBAS34-WW-ENG.pdfData sheet
Panduit FBAS34-WW-ENG cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Panduit
Catalog no.
FBAS34-WW-ENG
Product type
Communications
MasterFormat
27
Cut sheet
PDF · manufacturer current

Product details

Catalog numberFBAS34-WW-ENG
DescriptionPanduit Indoor-Outdoor Ribbon Cable (Optical Fiber Cable). Model FBAS34-WW-ENG. Singlemode fibers (ITU G.657.A2/B2); Attenuation max 0.4dB/km at 1310nm and 0.3dB/km at 1550nm; Maximum tensile rating 600 lb (2670 N); Installation temperature range -4°F to +140°F (-20°C to +60°C). material: All-dielectric, LSZH, OFNR, EuroClass
Connection size144 to 864 fibers
End connection12-fiber MPO style connectors
FinishYellow jacket
MountingLadder rack, ducts, building-to-building
Dimensions0.41 to 0.77 inches (10.5 to 19.5 mm) diameter.
