DIV 27 · COMMUNICATIONSCOMMUNICATIONSCUT SHEET INDEXED

PanduitFiberRunner 4x4 GlobalFRSP27--WW-ENG

Panduit Fiber optic cable routing system (FiberRunner). Model FRSP27--WW-ENG. 50% fill capacity for 1.6mm cable is 2,824 strands; 50% fill capacity for 3.0mm cable is 803 strands; Maintains minimum 2 inch bend radius; Open channel cross-sectional area is 17.6 in² (11,354 mm²). material: Rigid PVC (Channel), PC/ABS (Fittings)

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFFRSP27--WW-ENG.pdfData sheet
Panduit FRSP27--WW-ENG cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Panduit
Catalog no.
FRSP27--WW-ENG
Product type
Communications
MasterFormat
27
Cut sheet
PDF · manufacturer current

Product details

Catalog numberFRSP27--WW-ENG
DescriptionPanduit Fiber optic cable routing system (FiberRunner). Model FRSP27--WW-ENG. 50% fill capacity for 1.6mm cable is 2,824 strands; 50% fill capacity for 3.0mm cable is 803 strands; Maintains minimum 2 inch bend radius; Open channel cross-sectional area is 17.6 in² (11,354 mm²). material: Rigid PVC (Channel), PC/ABS (Fittings)
Connection size4x4
End connectionQuikLock Couplers
FinishYellow and Black
MountingLadder rack, threaded rod, auxiliary framing, strut, equipment racks, cabinets, raised floor pedestals
Dimensions4.44 in x 5.05 in (112.8 mm x 128.3 mm).
