PanduitPan-Way® T-70 Surface Raceway System Specificaion Sheet FRSP34FRSP34

Panduit Non-metallic multi-channel surface raceway (Surface Raceway). Model FRSP34. Rated for 600 volts between conductors; Flammability rating UL94 V-0 and FT4; Accepts NEMA standard snap-on or screw-on faceplates; Tamper-resistant design for security. material: Rigid PVC

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFFRSP34.pdfData sheet
Panduit FRSP34 cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Panduit
Catalog no.
FRSP34
Product type
Communications
MasterFormat
27
Cut sheet
PDF · manufacturer current

Product details

Catalog numberFRSP34
DescriptionPanduit Non-metallic multi-channel surface raceway (Surface Raceway). Model FRSP34. Rated for 600 volts between conductors; Flammability rating UL94 V-0 and FT4; Accepts NEMA standard snap-on or screw-on faceplates; Tamper-resistant design for security. material: Rigid PVC
FinishPure color, scratch and dent resistant
MountingSurface mounted
Dimensions70mm channel opening; 1" minimum bend radius
ComplianceUL 5A, CSA C22.2 No. 62.1-03, UL 94 V-0, FT4, NEC Article 388
Voltage600VAC.
