PanduitPanduit Turn-Tell Labels Technical

Name: Panduit Panduit Turn-Tell Labels Technical
Brand: Panduit
SKU: Panduit Turn-Tell Labels Technical

Panduit Wire/Cable Label (Cable Management). Model V*T, V*C. Service Temperature Range: -40°F to 150°F (-40°C to 65.6°C)

Free to start · No card required · The agent pulls this cut sheet in automatically

Product details

Catalog number	Panduit Turn-Tell Labels Technical
Description	Panduit Wire/Cable Label (Cable Management). Model VT, VC. Service Temperature Range: -40°F to 150°F (-40°C to 65.6°C)
Print Method	Thermal transfer; Peel Adhesion to Stainless Steel: 32 oz/in width minimum
UV Resistance	3000 hours no change observed. material: Clear polymer film with acrylic pressure sensitive adhesive
Finish	Clear film with colored print-on area
Mounting	Pressure sensitive self-laminating
Dimensions	VC: 4.5 +/- 0.5 mils; VT: 5.50 +/- 0.5 mils
Compliance	RoHS (2002/95/EC).
