DIV 27 · COMMUNICATIONSCOMMUNICATIONSCUT SHEET INDEXED

PanduitPan-Way® Hinged LDPH Raceway SystemSRSP30-WW-ENG

Panduit Hinged LDPH Raceway System (Raceway). Model SRSP30-WW-ENG. Single-channel, non-metallic, pre-assembled two-piece hinged cover design; Rated for 600VAC power applications; Includes full-length adhesive backing for tool-free installation; Minimum 1-inch (25.4mm) bend radius fittings available. material: Rigid PVC

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFSRSP30-WW-ENG.pdfData sheet
Panduit SRSP30-WW-ENG cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Panduit
Catalog no.
SRSP30-WW-ENG
Product type
Communications
MasterFormat
27
Cut sheet
PDF · manufacturer current

Product details

Catalog numberSRSP30-WW-ENG
DescriptionPanduit Hinged LDPH Raceway System (Raceway). Model SRSP30-WW-ENG. Single-channel, non-metallic, pre-assembled two-piece hinged cover design; Rated for 600VAC power applications; Includes full-length adhesive backing for tool-free installation; Minimum 1-inch (25.4mm) bend radius fittings available. material: Rigid PVC
FinishSmooth
MountingSurface mount with adhesive backing
DimensionsSizes: LDPH3, LDPH5, LDPH10
Lengths6', 8', 10'
ComplianceUL94V-0; FT4; UL-5A 600VAC; CSA C22.2 No. 62.1-03; NEC Article 388
Voltage600VAC.
