Watts
Watts Dielectric Union (Dielectric Unions). Model Series 3008. Prevents galvanic corrosion between dissimilar metals; Rated to 180°F (82°C) at 250psi (17.2 bar); Factory certified to withstand 600 volts on a dry line; Standard gasket is Buna-N; optional EPDM for steam/hot water. material: Gray Iron, Malleable Iron, Steel, Brass, Bronze, Zinc
Free to start · No card required · The agent pulls this cut sheet in automatically
- Manufacturer
- Watts
- Catalog no.
- Product type
- Plumbing
- MasterFormat
- 22
- Cut sheet
- PDF · manufacturer current
Product details
| Catalog number | |
|---|---|
| Description | Watts Dielectric Union (Dielectric Unions). Model Series 3008. Prevents galvanic corrosion between dissimilar metals; Rated to 180°F (82°C) at 250psi (17.2 bar); Factory certified to withstand 600 volts on a dry line; Standard gasket is Buna-N; optional EPDM for steam/hot water. material: Gray Iron, Malleable Iron, Steel, Brass, Bronze, Zinc |
| Connection size | 1/2", 3/4", 1" (15, 20, 25mm) |
| End connection | Female brass pipe thread to female solder |
| Pressure Rating | 250psi (17.2 bar) |
| Dimensions | A: 1 1/12" to 1 7/8"; B: 38mm to 64mm |
| Compliance | ASTM A48-83, ASTM A-197-79, ASTM A108, ASTM B-16, AS |
