DIV 22 · PLUMBINGWATER CLOSETS & BIDETSCUT SHEET INDEXED

American StandardActiClean® Chair Height Elongated Toilet Bowl3070A101

American Standard Elongated Complete Toilet (Toilet). Model 714AA.154. Self-cleaning system with Quick Clean (1 min) and Deep Clean (10 min) cycles; Battery operated cleaning system (4AA batteries, up to 1 year life); 16-1/2" (419mm) rim height for ADA accessible applications; 1,000g MaP score with 2-1/16" fully glazed trapway. material: Vitreous china

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDF3070A101.pdfData sheet
American Standard 3070A101 cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
American Standard
Catalog no.
3070A101
Product type
Water Closets & Bidets
MasterFormat
22
Cut sheet
PDF · manufacturer current

Product details

Catalog number3070A101
DescriptionAmerican Standard Elongated Complete Toilet (Toilet). Model 714AA.154. Self-cleaning system with Quick Clean (1 min) and Deep Clean (10 min) cycles; Battery operated cleaning system (4AA batteries, up to 1 year life); 16-1/2" (419mm) rim height for ADA accessible applications; 1,000g MaP score with 2-1/16" fully glazed trapway. material: Vitreous china
Connection size12" (305mm) rough-in
Flow Rate4.8 Lpf/1.28 gpf
FinishWhite
MountingFloor mounted
Dimensions30-3/16" x 20-11/16" x 31-3/8" (767 x 526 x 797mm).

Also cataloged as: 3070A101.020, 3070A101.222
