DIV 22 · PLUMBINGSHOWERSCUT SHEET INDEXED

American StandardSerin 2.5 GPM Shower Trim Kit with Lever HandleT064501

American Standard Pressure Balance Bath/Shower Fitting (Serin). Model T064.501. 3-Function Modern Showerhead; Washerless ceramic disc valve cartridge; Pressure balancing cartridge maintains constant output temperature; Adjustable hot limit safety stop. material: Cast brass body, metal lever handle, metal wall escutcheon

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFT064501.pdfData sheet
American Standard T064501 cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
American Standard
Catalog no.
T064501
Product type
Showers
MasterFormat
22
Cut sheet
PDF · manufacturer current

Product details

Catalog numberT064501
DescriptionAmerican Standard Pressure Balance Bath/Shower Fitting (Serin). Model T064.501. 3-Function Modern Showerhead; Washerless ceramic disc valve cartridge; Pressure balancing cartridge maintains constant output temperature; Adjustable hot limit safety stop. material: Cast brass body, metal lever handle, metal wall escutcheon
Connection size1/2" inlets and outlets
End connectionDirect sweat, threaded, or PEX (varies by rough valve model)
Flow Rate2.5 gpm / 9.5 L/min max
MountingRough-in plaster guard for thin-wall mounting.

Also cataloged as: T064501.002, T064501.295
