BroanA130E65RS

Broan Energy Recovery Ventilator (ERV) (Fresh Air Systems). Model A130E65RT. SRE of 67% at 0°C and 56% at -25°C; PMSM ECM motors for energy efficient operation; Integrated electronic airflow measurement with LCD screen; Includes MERV 8 grade washable standard filter. material: Galvanized steel door and cabinet, expanded polystyrene insulation shell, polypropylene crossflow core

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDFA130E65RS.pdfData sheet
Broan A130E65RS cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Broan
Catalog no.
A130E65RS
Product type
Ventilation
MasterFormat
23
Cut sheet
PDF · manufacturer current

Product details

Catalog numberA130E65RS
DescriptionBroan Energy Recovery Ventilator (ERV) (Fresh Air Systems). Model A130E65RT. SRE of 67% at 0°C and 56% at -25°C; PMSM ECM motors for energy efficient operation; Integrated electronic airflow measurement with LCD screen; Includes MERV 8 grade washable standard filter. material: Galvanized steel door and cabinet, expanded polystyrene insulation shell, polypropylene crossflow core
Connection size5" ports
End connectionTop ports
Flow Rate35 to 131 CFM (17 to 62 L/s) @ 0.2 in. w.g.
MountingSuspended or Wall-mount
Dimensions12" x 12" x 9" (30.5 cm x 30.5 cm x 23 cm).
