Legrand1115

Name: Legrand 1115
Brand: Legrand
SKU: 1115

Legrand Ladder Cable Tray Straight Section (Cable Tray). Model CS 1115 13 CB. Construction: Welded

Free to start · No card required · The agent pulls this cut sheet in automatically

Product details

Catalog number	1115
Description	Legrand Ladder Cable Tray Straight Section (Cable Tray). Model CS 1115 13 CB. Construction: Welded
Bottom Type	Ladder (1" wide I rung) or Solid Bottom (Flat Sheet over 12" Rung Spacing)
Grounding Capability	2000 ampere rating, UL Cross Sectional area 2.00 in²; Connector Splice Resistance: Less than 0.00033 ohms. material: Aluminum Alloy 6063-T6
Finish	Plain
Dimensions	Widths: 6, 9, 12, 18, 24, 30, 36 inches
Side Rail Height	7 inches
Compliance	NEMA VE1, CSA C22.2 No. 126, NEC 392.60.
