DIV 26 · ELECTRICALELECTRICALCUT SHEET INDEXED

Legrand310

Name: Legrand 310
Brand: Legrand
SKU: 310

Legrand Two Rail Ladder Cable Tray (Cable Tray). Model CS 310 CB 55. NEMA Tray Type: Two Rail Ladder

Free to start · No card required · The agent pulls this cut sheet in automatically

Product details

Catalog number	310
Description	Legrand Two Rail Ladder Cable Tray (Cable Tray). Model CS 310 CB 55. NEMA Tray Type: Two Rail Ladder
Side Rail Height	6" with 1 3/4" top flange
Rung Spacing	9" (Standard for Series 2)
Grounding Capability	Classified as equipment grounding conductor per NEC 392.7 (Max 400A). material: Commercial quality steel / ASTM A-1008 / A-1011
Finish	Hot-dip galvanized after fabrication / ASTM A-123
Dimensions	6" side rail, 5" load depth, 1" wide box rung
Compliance	NEMA Class 20C, CSA Class E, 6M, UL Listed (File No. E60796).
