DIV 26 · ELECTRICALELECTRICALCUT SHEET INDEXED

Legrand428

Legrand J-Hook with Knock on Steel Beam Clamp (Cable Management). Model CS 428 RA 10 CB. Fits flange thickness 1/8" to 1/4"; Load test 65 lbs; Cable retainer included; Nominal capacity Cat.5e .19 (119), Cat.6 .23 (81), Cat 6A .30 (48). material: Steel

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDF428.pdfData sheet
Legrand 428 cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Legrand
Catalog no.
428
Product type
Electrical
MasterFormat
26
Cut sheet
PDF · manufacturer current

Product details

Catalog number428
DescriptionLegrand J-Hook with Knock on Steel Beam Clamp (Cable Management). Model CS 428 RA 10 CB. Fits flange thickness 1/8" to 1/4"; Load test 65 lbs; Cable retainer included; Nominal capacity Cat.5e .19 (119), Cat.6 .23 (81), Cat 6A .30 (48). material: Steel
Connection size2"
FinishPre-Galvanized
MountingSteel Beam
DimensionsHeight 4.79", Width 1.5", Hook Opening 2", Hole .26"
ComplianceNEC, TIA568-C, TIA569-C, RoHS.
  • Official cut sheet, indexed
  • Auto-matched to your schedule
  • Cover + TOC, one click
