DIV 26 · ELECTRICALELECTRICALCUT SHEET INDEXED

Legrand5252-ISP

Legrand Duplex Receptacle (TVSS & Isolated Ground Devices). Model 5252-SP, 5352-SP. 15A and 20A ratings at 125VAC; NEMA 5-15R and 5-20R configurations; Three-mode TVSS protection with 170 Joules absorption per leg; Solid-state LED monitor with 25-year minimum life. material: Thermoplastic body, steel strap, copper-alloy contacts

Add to a submittalDownload cut sheet

Free to start · No card required · The agent pulls this cut sheet in automatically

PDF5252-ISP.pdfData sheet
Legrand 5252-ISP cut sheet — first page
Official manufacturer data sheetOpen PDF ↗
Manufacturer
Legrand
Catalog no.
5252-ISP
Product type
Electrical
MasterFormat
26
Cut sheet
PDF · manufacturer current

Product details

Catalog number5252-ISP
DescriptionLegrand Duplex Receptacle (TVSS & Isolated Ground Devices). Model 5252-SP, 5352-SP. 15A and 20A ratings at 125VAC; NEMA 5-15R and 5-20R configurations; Three-mode TVSS protection with 170 Joules absorption per leg; Solid-state LED monitor with 25-year minimum life. material: Thermoplastic body, steel strap, copper-alloy contacts
Connection size#14 – #10 AWG
End connectionScrew-pressure-plate back and side wire
FinishIvory, White, Gray, Light Almond, Blue
MountingWrap-around steel strap
Dimensions3.82" x 2.80" x 1.225".

Also cataloged as: 5252-WSP, 5252-GRYSP, 5252-LASP, 5252-BLSP, 5352-ISP, 5352-WSP, 5352-GRYSP, 5352-LASP, 5352-BLSP
