LegrandAV1000BK

Name: Legrand AV1000BK
Brand: Legrand
SKU: AV1000BK

Legrand AV Connector (AVIP Connector Series). Model SP-AVIPSeriesDev-WM. Contact resistance: 10 Ω (VGA/USB/HDMI), 3-5 mΩ (BNC/RCA)

Free to start · No card required · The agent pulls this cut sheet in automatically

Product details

Catalog number	AV1000BK
Description	Legrand AV Connector (AVIP Connector Series). Model SP-AVIPSeriesDev-WM. Contact resistance: 10 Ω (VGA/USB/HDMI), 3-5 mΩ (BNC/RCA)
Insulation resistance	5 MΩ (VGA/USB/HDMI), 500 MΩ (RCA/BNC); Dielectric withstanding voltage: 300 VDC / 10 msec or 500 VAC / 1 min
Insulator material	PBT glass fiber reinforced UL 94 VO. material: Brass, PBT glass fiber reinforced
End connection	VGA, BNC, USB, RCA, HDMI
Finish	Gold plated over nickel, Tin plated
Mounting	Single plate
Compliance	UL 94 VO
Voltage	300 VDC / 10 msec, 500 VAC / 1 min.
