Legrand 0-10V Dimmer (Lighting Control). Model CD4FBL3P, CD4FBL. Maximum Rated Load: 120V 10A / 277V 5A
Free to start · No card required · The agent pulls this cut sheet in automatically
- Manufacturer
- Legrand
- Catalog no.
- Titan0
- Product type
- Electrical
- MasterFormat
- 26
- Cut sheet
- PDF · manufacturer current
Product details
| Catalog number | Titan0 |
|---|---|
| Description | Legrand 0-10V Dimmer (Lighting Control). Model CD4FBL3P, CD4FBL. Maximum Rated Load: 120V 10A / 277V 5A |
| Control Signal | 0-10VDC 30mA sink |
| Frequency | 60 Hz |
| Installation | Single Pole or 3-Way. finish: W, LA, I, BK, GRY, Brown |
| Mounting | Wall plate |
| Dimensions | 2.85" x 4.87" [72mm x 124mm] |
| Compliance | cULus Listed, UL1472, CSA-C22.2 No. 184.1-95, NEMA WD-1, NEMA WD-6, California Title 24 |
| Voltage | 120VAC / 277VAC. |
